一、滾珠絲杠的核心原理與結構組成

1、 The core principle and structural composition of ball screw

滾珠絲杠是一種將旋轉運動與直線運動相互轉換的傳動裝置，由六個關鍵部件精密配合組成：

Ball screw is an efficient transmission device that converts rotational motion into linear motion, consisting of six key components that are precisely matched:

螺桿：帶有精密螺旋槽的轉軸

Screw: a shaft with precision spiral grooves

螺母：內部設有匹配螺旋槽的套件

Nut: Kit with matching spiral groove inside

鋼球：在螺旋槽中滾動的傳動介質

Steel ball: a transmission medium that rolls in a spiral groove

預壓片：保持適當預緊力的關鍵部件

Pre pressing: a key component that maintains appropriate pre tension force

反向器：實現鋼球循環的通道裝置

Reversing device: a channel device for realizing the circulation of steel balls

防塵器：保護內部清潔的密封組件

Dustproof device: a sealing component that protects internal cleanliness

二、性能對比分析

2、 Performance comparison analysis

傳動效率表現：

Transmission efficiency performance:

滾珠絲杠：90%-99%（近乎零摩擦的滾動接觸）

Ball screw: 90% -99% (almost zero friction rolling contact)

滑動絲杠：25%-50%（存在較大滑動摩擦損耗）

Sliding screw: 25% -50% (with significant sliding friction loss)

精度等級差異：

Accuracy level difference:

滾珠絲杠：可達微米級定位精度

Ball screw: capable of micrometer level positioning accuracy

滑動絲杠：通常為毫米級精度

Sliding screw: usually with millimeter level accuracy

使用壽命對比：

Comparison of service life:

滾珠絲杠：可達數萬小時（低磨損設計）

Ball screw: up to tens of thousands of hours (low wear design)

滑動絲杠：數千小時后需更換（摩擦損耗嚴重）

Sliding screw: needs to be replaced after thousands of hours (due to severe friction loss)

三、應用場景選擇指南

3、 Application Scenario Selection Guide

（一）優先選擇滾珠絲杠的場合：

（1） Preferred occasions for choosing ball screws:

數控機床的進給系統

The feed system of CNC machine tools

精密測量設備定位平臺

Precision measuring equipment positioning platform

半導體制造設備

Semiconductor Manufacturing Equipment

需要配合伺服/步進電機使用的自動化設備

Automation equipment that needs to be used in conjunction with servo/stepper motors

高速、高精度、長壽命要求的場景

Scenarios requiring high speed, high precision, and long lifespan

（二）可考慮滑動絲杠的情況：

（2） Consider the case of sliding screw:

簡單力傳遞裝置

Simple force transmission device

對定位精度要求不高的手動調節機構

Manual adjustment mechanism with low requirements for positioning accuracy

需要自鎖功能的垂直升降裝置（部分型號）

Vertical lifting device requiring self-locking function (some models)

預算有限且使用頻率低的設備

Equipment with limited budget and low usage frequency

四、選型決策要素

4、 Selection decision elements

精度需求：根據設備定位要求選擇合適等級

Accuracy requirement: Select the appropriate level according to the equipment positioning requirements

負載條件：考慮軸向載荷和徑向載荷

Load conditions: Consider axial and radial loads

速度要求：高速應用必須選擇滾珠絲杠

Speed requirement: Ball screws must be selected for high-speed applications

使用環境：粉塵多或潮濕環境需特殊處理

Usage environment: Special treatment is required for dusty or humid environments

預算限制：平衡初期成本與長期維護費用

Budget constraint: Balancing initial costs and long-term maintenance expenses

通過以上對比分析，工程技術人員可以根據具體應用需求，在滾珠絲杠和滑動絲杠之間做出合理選擇，確保設備獲得的性能表現和使用壽命

Through the above comparative analysis, engineering and technical personnel can make a reasonable choice between ball screws and sliding screws according to specific application needs, ensuring that the equipment achieves the best performance and service life
